單元板參數 |
技術參數 (Technical parameters) |
單位UNTT |
參數值( parameters values ) |
物理點間距 (Pixel pitch) |
MM |
6 |
模塊尺寸 (Panel size) |
MM |
L192*H192*T13 |
物理密度 (Physical density) |
/㎡ |
27600 |
像素基色 (Pixel configuration) |
R/G/B |
1,1,1 |
驅動方式 (Driving method> |
|
1/8恒流掃描Constant current 1/8scan |
LED 封裝方式 (LED Encapsulation) |
SMD |
2525白燈 |
顯示分辨率 (Display resolution) |
DOTS |
32+32=1024 |
模塊重量 (Module weight) |
KG |
0.25 |
模塊接口 (Module port> |
|
HUB-HD75 (2) |
模塊工作電壓 (Module working voltage) |
VDC |
5 |
模塊功耗 (Module consumption ) |
W |
27 |
屏體參數 |
模塊視角 ( Viewing angle) |
Deg. |
140度 |
最佳視距 (Option distance> |
M |
4--30 |
驅動器件 (Driving device) |
|
2037 , 5020 |
每平米模塊數 (Every square metre module) |
PCS |
27.17 |
最大功耗 (Maximum power) |
W/M |
750 |
換幀頻率 (Frame Frequency |
HZ/S |
≥60 |
刷新頻率 ( Refresh frequency) |
HZ/S |
2037/1920 ,≥320/5020 |
白平衡亮度 (Equilibrium brightness) |
CD/M |
5000 |
工作環境溫度 (Working environmenttemperature ) |
℃ |
-10~60 |
工作環境濕度 (Workingenvironmenthumidity) |
℃ |
10%~70% |
屏體工作電壓 (Display working voltage) |
RH |
AC47~63HZ,220V士15%/110V士15% |
白場色溫 (Colour temperature) |
VAC |
10000K |
|
|
|
灰度/顏色 (Gray scaleicolor) |
|
≥16.7M color |
輸入信號 (Input signal ) |
|
RF\ S-Video\ RGB etc |
控制系統 (Control system) |
|
PCTV非線性卡nonlincarity card,DVI顯卡display card,Linsn control system,靈星雨 |
平均無故障時間 (Mean free error time) |
HOURS |
>5000 |
壽命 (Lifc) |
HOURS |
100000 |
雜點率 (Lamp failure frequency) |
|
<0.0001 |
抗干擾 (Antijam) |
|
IEC801 |
安全 (Safety) |
|
GB4793 |
抗電擊 (Resist the electricity> |
|
1500v last 1min無擊穿及飛狐No breakdown |
屏體重量 (Steel box weight) |
KG/㎡ |
45(標準箱體standard steel box) |
漏電電流 (Earth leakage current) |
mA |
|
P等級 (IPrating) |
|
The back IP40,The front IP50 |
箱體尺寸(參考) (Steel box size) |
mm |
L768*h768*100 |
